Cooling Tower

Our Cooling Towers are designed to deliver efficient heat dissipation for industrial and commercial systems. Manufactured with high-quality materials, they offer excellent durability, corrosion resistance, and reliable performance under demanding conditions.


Availability:



Inquire

Cooling Tower Industrial Cooling Tower Water Cooling Tower Energy Efficient Cooling Tower

Detail Information

Product Description

Core Advantages

1. Description of Cooling Tower

Parameter name	Parameter value
Square of cooling tower, m2	64
The hydraulic load (water flow), m3/hour - minimal	400
The hydraulic load (water flow), m3/hour - nominal	800
The hydraulic load (water flow), m3/hour - maximal	1200
Water pressure at the cooling tower input, MCE (kgf/cm2)	3÷15
Temperature difference Δt, °C	5,20
Thermal load at u=30°C, t=20°C, φ=40%, Megacalories/h (kW)	8000
Droplet entrainment, %	0,01
Water evaporation, from water consumption (average)	1,07
Diameter of the fan, mm	5000÷4500
Consumed power of electromotor, kW	37÷40
Rotation rate	250÷290
Noise level (10 meters from cooling tower), dB	85 dB
Dimension Sizes (length x wide x height), mm	8x8x6,9
Allowable temperature of the water at the cooling tower input, (t1), °C	Not more than 65
Branch pipe of water supply (byl), mm	400
u - the air temperature according to air dry bulb thermometer; t - the air temperature according to air wet bulb thermometer; φ - relative humidity of air.

2. Specification

Component	Material
Body	Hot dipped galvanized steel
Fan stack	FRP
Casing	FRP
Fill	PVC / PP (upon request)
Drift eliminator	PVC / PP (upon request)
Pipes	FRP
Nozzles	PP / ABS (upon request)
Air guides	PP / Galvanized steel
Fan instalation	PAG (blades), Al (hub)
Fan support	Hot dipped galvanized steel
Connecting elements	Cink Steel
Water tray	FRP
Fan protection	Cink Steel
Motor housing	Color coated steel

Ideal for HVAC, power plants, chemical processing, and manufacturing industries, our cooling towers help maintain optimal system temperatures, reduce energy consumption, and ensure long-term operational stability.

Product advantages

✔ Efficient heat exchange performance
✔ Corrosion-resistant materials for extended lifespan
✔ Low noise and energy-saving design
✔ Compact structure, easy to install and maintain
✔ Suitable for various industrial and commercial applications

Tower Structure

The tower’s framework is constructed using pultruded FRP beams and columns, ensuring a lightweight yet durable structure with outstanding corrosion resistance and mechanical strength. This robust framework supports all components securely while maintaining long-term stability under harsh environmental conditions.

Cooling Tower for Chemical Plants

Mechanical Equipment

The mechanical system—comprising the fan, gearbox, drive shaft, and motor—ensures smooth and efficient air circulation throughout the cooling tower. Each component is engineered for optimal performance, featuring low vibration, high energy efficiency, and reliable continuous operation.

Cooling Tower Film Fills

The cooling fills, made of high-quality PVC or polypropylene, are carefully designed to optimize air–water interaction. By increasing the surface area for heat exchange, the fills allow water to form thin, uniform films that accelerate cooling and significantly improve thermal performance and overall system efficiency.
