Laboratory Acid Mist Purification Tower

The Laboratory Acid Fume Scrubber is a compact and highly efficient system designed to safely capture and neutralize acid fumes and corrosive gases generated in laboratory environments. It is widely used in research institutes, universities, chemical laboratories, and testing facilities to ensure a safe, clean, and compliant working atmosphere.


Availability:



Inquire

Laboratory Acid Mist Purification Tower Laboratory Acid Fume Scrubber Lab Acid Mist Purification Tower Lab Fume Scrubber System Laboratory Exhaust Gas Purification Acid Mist Removal for Labs

Detail Information

Core Advantages

Product Description

Place Of Origin:	CHINA
Processing Capacity:	1200~30000 M3/H
Supply Ability:	50 Sets Per 3 Months
Material:	PP/FRP
Purifying Rate:	>90%
Packaging Details:	Pallets
Highlight:	Acid Mist Absorption Tower, Acid Mist Purification Tower, Purification Tower 30000 M3/H

High Purification Efficiency:
The purification efficiency generally reaches 85%–95%, effectively removing a wide range of acid gases.

Wide Applicability:
Capable of treating various types of acid exhaust gases, suitable for chemical, metallurgy, electroplating, and other industrial fields.

Energy Saving and Environmentally Friendly:
By combining a packing layer with an efficient spray system, the tower enhances absorption efficiency and allows for absorption liquid recycling, reducing both energy and material consumption while meeting environmental protection standards.

Low Operating Costs:
The system features a compact structure, low resistance, and simple operation, which collectively reduce long-term operating costs.

Safe and Reliable:
Designed and manufactured with multiple safety protection measures to ensure stable and secure operation under various working conditions.

Easy Maintenance:
Operators can easily learn the operating procedures with minimal training. The equipment is simple to maintain and designed for long-term stable use.

1. Description of acid mist purification tower

Laboratory Acid Mist Purification Tower

Number	Item	Material	Remarks
1	The maintenance port	PP/PVC	can be used as a viewing window
2	Spray port	PP/PVC
3	tower body	PP
4	filler inlet and outlet	PP/PVC	can be used as a viewing window
C	water inlet	PP
6	reservoir	PP
7	overflow port	PP
8	circulating water outlet	PP
9	sewage outlet	PP
10	air inlet	PP

2. Main product models

Model	Blowing rate M3/H	φ	φ1	φ2	H1	H	Purifying rate >90%	Recommended water pump
XTS-500	1200	500	200	800	1200	3500	>90%	25FP-8
XTS-600	2000	600	200	1000	1200	3500	>90%	25FP-8
XTS-700	3000	700	300	1000	1400	4000	>90%	32FP-11
XTS-800	4000	800	300	1200	1400	4000	>90%	32FP-11
XTS-1000	5000	1000	400	1400	1400	4500	>90%	40FP-18
XTS-1200	6000	1200	450	1600	1600	4500	>90%	40FP-18
XTS-1400	8000	1400	500	1800	1600	5000	>90%	50FP-22
XTS-1600	10000	1600	600	2000	1800	5000	>90%	50FP-22
XTS-1800	15000	1800	700	2200	2000	5500	>90%	50FP-22
XTS-2000	20000	2400	800	2400	2200	5500	>90%	65FP-26
XTS-2200	25000	2600	1000	2600	2500	6000	>90%	65FP-26
XTS-2500	30000	2800	1000	2800	2500	6000	>90%	65FP-26

3. Packaging & Shipping

We can pack it by pallet, or according to the customers' specific requirements.

Port: Shanghai/Ningbo

4. Our Services

In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Correct technological process control
(4) Remove simple problem

Any doubt please contact us.
