Exhaust Gas Treatment System

Our Exhaust Gas Treatment System is an advanced air pollution control solution designed to effectively remove harmful gases, chemical fumes, acid mists, volatile organic compounds (VOCs), and particulate matter from industrial emissions. The system is widely applied in industries such as chemical manufacturing, metal processing, semiconductor production, photovoltaic cell fabrication, and electroplating.


Availability:



Inquire

Exhaust Gas Treatment System Air Pollution Control System Waste Gas Purification System

Detail Information

Core Advantages

Product Description

Place Of Origin:	CHINA
Processing Capacity:	1200~30000 M3/H
Supply Ability:	50 Sets Per 3 Months
Material:	PP/FRP
Purifying Rate:	>90%
Packaging Details:	Pallets
Highlight:	Purification Tower 30000 M3/H

Utilizing a combination of wet scrubbing, activated carbon adsorption, demisting, and optional catalytic or thermal oxidation, the system ensures compliance with stringent environmental regulations while maintaining operational efficiency and safety.

Constructed from corrosion-resistant materials such as FRP, PP, PVC, or stainless steel, our system is engineered for long-term use in harsh chemical environments and can be customized to suit specific gas compositions and flow rates.

Key Features:

High removal efficiency for acid gases, NOx, SO₂, HCl, HF, NH₃, VOCs, and other hazardous pollutants
Customizable designs for air volume, material selection, and control method
Modular structure for easy installation and maintenance
Real-time monitoring system (optional) for emission data tracking
Low operating cost, energy-efficient design

Applications:

Chemical and pharmaceutical factories
Metal smelting and pickling workshops
Semiconductor and solar cell production lines
Battery manufacturing and recycling plants
Laboratory exhaust gas purification

Available Types:

Wet scrubber towers (single or multi-stage)
Dry filtration + activated carbon systems
Packed bed absorption systems
NOx treatment and acid mist control towers
Integrated VOC + acid gas control units

1. Description of Exhaust Gas Treatment System

Waste Gas Treatment Equipment for Battery, Semiconductor & Lithium Industry

Number	Item	Material	Remarks
1	The maintenance port	PP/PVC	can be used as a viewing window
2	Spray port	PP/PVC
3	tower body	PP
4	filler inlet and outlet	PP/PVC	can be used as a viewing window
C	water inlet	PP
6	reservoir	PP
7	overflow port	PP
8	circulating water outlet	PP
9	sewage outlet	PP
10	air inlet	PP

2. Main product models

Model	Blowing rate M3/H	φ	φ1	φ2	H1	H	Purifying rate >90%	Recommended water pump
XTS-500	1200	500	200	800	1200	3500	>90%	25FP-8
XTS-600	2000	600	200	1000	1200	3500	>90%	25FP-8
XTS-700	3000	700	300	1000	1400	4000	>90%	32FP-11
XTS-800	4000	800	300	1200	1400	4000	>90%	32FP-11
XTS-1000	5000	1000	400	1400	1400	4500	>90%	40FP-18
XTS-1200	6000	1200	450	1600	1600	4500	>90%	40FP-18
XTS-1400	8000	1400	500	1800	1600	5000	>90%	50FP-22
XTS-1600	10000	1600	600	2000	1800	5000	>90%	50FP-22
XTS-1800	15000	1800	700	2200	2000	5500	>90%	50FP-22
XTS-2000	20000	2400	800	2400	2200	5500	>90%	65FP-26
XTS-2200	25000	2600	1000	2600	2500	6000	>90%	65FP-26
XTS-2500	30000	2800	1000	2800	2500	6000	>90%	65FP-26

3. Packaging & Shipping

We can pack it by pallet, or according to the customers' specific requirements.

Port: Shanghai/Ningbo

4. Our Services

In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Correct technological process control
(4) Remove simple problem

Any doubt please contact us.
